Description

The NFC wristband has a memory capacity of 868 byte (NDEF), which is enough for creating digital business cards, recording of working times or unlocking your phone automatically.

The black/grey wristband is made of silicone, so it is absolutely waterproof. It has a length of 26 cm and a width of 2.7 cm overall. The NFC microship is integrated in the middle of the wristband, where it is 5 mm thick. Overall the wristband has a weight of 24 gram. The wristband is adjustable in size, so that it is suitable for a wrist extent between 16 cm and 22 cm.

Specification

Chip: NXP NTAG 216 (NTAG216) – 924 Byte (NDEF: 868 Byte)
Dimensions: 259x21x5mm
Color: Custom
Material: Silicone
Operating range: 1 – 100 mm (depending on the hardware)
Type: Wristband
Chip functions: 7 Byte UID, 24-bit Counter, 32-bit Passwort, ASCII Mirror, Datentransfer 106 kbit/s, ECC based originality signature, Schreibschutz, true anticollision, UID ASCII Mirror, wiederbeschreibar
Chip standards: 13.56 MHz, ISO 14 443-2 A, ISO 14 443-3 A, NFC-Forum Typ 2
Characteristics: Flexible, compatible with all NFC-enabled smartphones, robust waterproof

Features & functions

The wristband contains the NTAG 216, which has a memory capacity of 924 byte (NDEF: 868 byte). This chip comes along with the UID ASCII Mirror Feature, which allows to attach the UID of the chip to the NDEF message. Additionally, the chip contains a NFC counter, which counts the times a NFC tag is read. Both functions are deactivated by default. Further information about this chip and other NFC chip types you can find here. We also provide you with a download of the technical documentation by NXP.

Application

Musical Concert; Football Ticket, other events
Bars, Nightclubs, Fairs, Festival & Carnivals
Hotels, Resorts & Cruise Lines
Water park, Theme & Amusement Parks
Science centers, Zoos;
Racing, Bowling & Sporting events
For help of Lock Kids
For Identification of Puppies, Access Control

For futher details,please email diretor@idcardtech.com
