Description

The asset management anti-metal tag is an RFID electronic tag packaged with special materials, which technically solves the problem of management and use of ordinary anti-metal tags that cannot be attached to irregular or curved metal shelves or asset displays. The anti-metal electronic tag has good reading performance on the metal, even farther than reading in the air. The asset management anti-metal tag complies with the EPC C1G2 (ISO 18000-6C) standard agreement. The flexible printable asset management anti-metal tag can use RFID tag printers to print product information.

Specification

Main technical parameters
Communication protocol: EPC C1G2 (ISO18000-6C)
Working frequency: 860~960MHz
Integrated chip: Impinj Monza R6-P, or specified
Storage space: 32(64)bits
User memory space: 128(96)bits
Identification distance on metal: 6m
Identification distance on non-metals: 3~4m
Environmental protection: RoHS compliant
Data retention: more than 10 years
Erase/Write Cycles: 100,000 times
Packaging material: special electronic material + AL
Appearance size: 60×20×4.5mm, can be customized
Applicable temperature: -40℃~+80℃
Installation: rivets, magnets adsorption or gluing
Tag data information: LOGO and pattern and coding preprint

Application

Library Management

Item level management

RFID Asset tracking management

Hospital equipment management

Metal devices supply chain management
